Baumalight MS960 Skid Steer Mulcher | 60" Heavy Duty Fixed Tooth Brush Mulcher

The Baumalight MS960 Skid Steer Mulcher is a 60-inch heavy-duty fixed-tooth brush mulcher built for average to large skid steers and compact track loaders. Designed for serious brush clearing, vegetation management, fence line cleanup, farm clearing, trail work, hunting property maintenance, and entry-level forestry applications, the MS960 gives operators a stronger, heavier-duty mulching head than Baumalight’s 500 Series models while still keeping the rotor close to the carrier for improved weight management.

With a 75-inch path width, 60-inch rotor width, 18.5-inch rotor diameter, 860 lb rotor weight, 38 R9000 double-tipped cutters, and a universal skid steer quick-attach mount, the Baumalight MS960 is made for operators who need a compact but aggressive skid steer forestry mulcher that can handle dense brush, small trees, vines, fence rows, and heavy ground-contact applications.

The MS960 is available with multiple bent-axis piston motor options and an optional variable two-speed motor. To get the best performance, choose the motor that places your skid steer’s hydraulic flow near the upper end of that motor’s recommended GPM range. Running near the top of the correct motor range helps increase rotor speed, improve recovery, and keep the mulcher cutting efficiently.

Key Features of the Baumalight MS960 Brush Mulcher

• 60" rotor width for productive brush and small-tree clearing
• 75" path width to cover ground efficiently with full-size skid steers and CTLs
• Universal skid steer quick-attach mount for broad machine compatibility
• 38 R9000 double-tipped cutters for aggressive heavy-duty mulching
• 18.5" rotor diameter with an 860 lb rotor for strong cutting momentum
• Critical case drain requirement for hydraulic motor protection
• Bent-axis piston motor options to match different hydraulic flow ranges
• Optional variable two-speed motor to help balance rotor speed and torque in changing material
• Replaceable bolt-in AR400 wear plates for easier service and longer housing life
• Integrated push bar to help control brush and standing material
• Directional felling hook built into the pusher bar for better control of small trees and limbs
• Adjustable skid shoes for setting cutting height
• Large pressure gauge to help monitor hydraulic load and avoid unproductive relief pressure
• 3/8" rear chain curtain to help control material discharge
• Wire protection kit to help protect the rotor shaft from fencing and wire debris
• Heavy-duty T1 alloy tool steel frame built for demanding mulching applications
• Improved operator visibility for better control during clearing
• Spring-loaded hose support to help protect hydraulic hoses during curl and rollback
• Free replacement belt and 6 free replacement teeth included with the MS960

Baumalight MS960 Specifications

Model	Baumalight MS960
Attachment Type	Heavy Duty Fixed Tooth Skid Steer Brush Mulcher
Mount	Universal Skid Steer Quick Attach
Path Width	75"
Rotor Width	60"
Minimum Carrier Weight	7,000 lbs
Cutting Depth	1.5" above grade to 2" below grade
Holder Style	Fixed
Tool Style	Double Tipped
Tooth Part Number	R9000
Number of Cutters	38
Rotor Diameter	18.5"
Rotor Weight	860 lbs
Case Drain	Critical
Hydraulic Couplers	Not included
Unit Shipping Weight	2,975 lbs

Hydraulic Motor Options for the Baumalight MS960

The Baumalight MS960 should be paired with the correct bent-axis piston motor based on your skid steer’s auxiliary hydraulic flow. Do not automatically choose the biggest motor. The best motor is usually the one where your machine’s GPM lands near the high end of that motor’s operating range. This gives the mulcher the best chance to maintain faster rotor speed and recover quickly after engaging brush or small trees.

Example: If your machine produces 30 GPM, the C930 motor is already at the top of its charted flow range. If your machine produces 35 GPM, the C940 is the better match. If your machine produces 40 GPM, the C950 is the better match. If your machine produces 45–50 GPM, the C970 becomes the better pairing. For machines with very wide flow ranges or operators who want speed and torque flexibility, the D97X2 two-speed motor may be the best option.

Motor Option	Best Hydraulic Flow Match	Charted Rotor Speed Reference	Case Drain	Best Fit
C930 Bent-Axis Piston	20–30 GPM	1,450 RPM at 20 GPM / 1,800 RPM at 25 GPM / 2,100 RPM at 30 GPM	Critical	Standard-flow and lower high-flow skid steers near 25–30 GPM
C940 Bent-Axis Piston	25–35 GPM	1,500 RPM at 25 GPM / 1,800 RPM at 30 GPM / 2,100 RPM at 35 GPM	Critical	High-flow skid steers around 32–35 GPM
C950 Bent-Axis Piston	30–40 GPM	1,600 RPM at 30 GPM / 1,875 RPM at 35 GPM / 2,140 RPM at 40 GPM	Critical	High-flow compact track loaders around 37–40 GPM
C970 Bent-Axis Piston	35–50 GPM	1,400 RPM at 35 GPM / 1,630 RPM at 40 GPM / 1,830 RPM at 45 GPM / 2,030 RPM at 50 GPM	Critical	Very high-flow skid steers and CTLs around 45–50 GPM
D97X2 Two-Speed Motor	Adjustable high-flow setup	Variable / adjustable setup based on machine flow and material load	Critical	Operators who want a two-speed setup to balance rotor speed and torque in changing material

Quick Motor Selection Guide by Skid Steer Flow

Your Skid Steer Hydraulic Flow	Recommended MS960 Motor	Why This Pairing Makes Sense
20–24 GPM	C930	Best available match for lower-flow machines that meet the MS960 carrier weight and pressure requirements.
25–30 GPM	C930	Keeps the machine near the upper end of the C930 range for faster rotor speed.
31–35 GPM	C940	Good match once the machine exceeds the C930 range and can operate near the top of the C940 range.
36–40 GPM	C950	Ideal for high-flow CTLs that can run close to 40 GPM for strong rotor speed.
41–50 GPM	C970	Best fixed-displacement piston motor match for very high-flow machines near 45–50 GPM.
Variable or changing high-flow demand	D97X2 Two-Speed	Best choice when the operator wants adjustable speed and torque for changing material conditions.

Rotor RPM Reference by Motor and Flow

The chart below is based on the provided Baumalight motor flow chart. Use this as a general pairing guide. Actual performance depends on hydraulic pressure, coupler size, hose restriction, case drain back pressure, machine condition, material density, and operator technique.

Motor	20 GPM	25 GPM	30 GPM	35 GPM	40 GPM	45 GPM	50 GPM	55 GPM	60 GPM	65 GPM	70 GPM	75 GPM
C930 Bent-Axis Piston	1450	1800	2100	-	-	-	-	-	-	-	-	-
C940 Bent-Axis Piston	-	1500	1800	2100	-	-	-	-	-	-	-	-
C950 Bent-Axis Piston	-	-	1600	1875	2140	-	-	-	-	-	-	-
C970 Bent-Axis Piston	-	-	-	1400	1630	1830	2030	-	-	-	-	-
D97X2 Two-Speed	Adjustable	Adjustable	Adjustable	Adjustable	Adjustable	Adjustable	Adjustable	Adjustable	Adjustable	Adjustable	Adjustable	Adjustable

Common Skid Steers and Compact Track Loaders for the Baumalight MS960

The MS960 is designed for full-size skid steers and compact track loaders with a universal skid steer quick-attach mount, adequate carrier weight, proper auxiliary hydraulic flow, proper hydraulic pressure, and a functioning case drain. Always confirm your exact machine specs before ordering.

Common machines that may be considered for the Baumalight MS960 include:

• Bobcat T740, T770, T870, S740, S770, S850
• CAT 279D, 289D, 299D, 299D3, 299D3 XE, 299D XHP
• John Deere 331G, 333G, 335 P-Tier, 333 P-Tier
• Kubota SVL95, SVL97-2
• Case TV370, TV380, TV450, TV620B
• New Holland C337, C345, C362, L334
• Takeuchi TL12, TL12V2, TL12R2
• ASV RT-75, RT-95, RT-120, RT-135
• Gehl RT255, V330
• Mustang 2500RT, 3200VT, 3300V
• JCB 3TS-8T, 3TS-8W, 270T, 300T, 325T
• Wacker Neuson ST45, ST50, ST45 high-flow configurations

Fitment warning: Skid steer model names alone do not guarantee compatibility. Before ordering, verify your machine’s auxiliary GPM, hydraulic PSI, operating weight, lift capacity, coupler size, return-line setup, electrical controls if needed, and case drain availability.

Who Should Buy the Baumalight MS960?

The Baumalight MS960 is a strong choice for operators who want a heavier-duty skid steer mulcher than a lighter brush cutter or smaller fixed-tooth head. It is especially useful for contractors and property owners dealing with thick brush, field edges, overgrown fence lines, small trees, saplings, trails, rural property cleanup, and vegetation management where ground contact is common.

This skid steer mulcher is ideal for:

• Land clearing contractors
• Farm and ranch property maintenance
• Fence line clearing
• Trail and hunting property maintenance
• Tree service companies
• Right-of-way cleanup
• Municipal vegetation management
• Utility and roadside clearing
• Large acreage cleanup
• Heavy brush and sapling removal

Ripper Teeth vs. Planer Teeth on the MS960

The Baumalight MS960 is part of the 900 Series, which is available with either Double Carbide Tipped Ripper teeth or Single Blade Planer teeth. Ripper teeth are the better general-purpose choice when you expect more ground contact, rocks, fence lines, dirt, vines, and mixed clearing conditions. Planer teeth are typically more efficient in cleaner material where there are fewer stones and less ground contact.

Why Buy the Baumalight MS960 from Skid Steer Store?

At Skid Steer Store, we help match the mulcher to your machine before you buy. The MS960 has multiple motor options, and choosing the wrong motor can reduce rotor speed, cutting efficiency, and overall performance. Our team can help confirm your skid steer’s hydraulic flow, pressure, case drain setup, coupler requirements, and carrier weight so you can order the right Baumalight MS960 configuration the first time.

Frequently Asked Questions

What size skid steer do I need for the Baumalight MS960?

The Baumalight MS960 requires a minimum carrier weight of 7,000 lbs. You should also confirm auxiliary hydraulic flow, hydraulic pressure, case drain availability, coupler size, and lift capacity before ordering.

What hydraulic motor should I choose for the Baumalight MS960?

Choose the bent-axis piston motor that places your skid steer’s GPM near the upper end of that motor’s flow range. For example, 30 GPM is best matched with the C930, 35 GPM with the C940, 40 GPM with the C950, and 45–50 GPM with the C970. The D97X2 two-speed motor is a good option when you want adjustable speed and torque for changing material conditions.

Does the Baumalight MS960 require a case drain?

Yes. The MS960 requires a case drain. The case drain helps protect the hydraulic motor by allowing internal leakage oil to return safely to the tank without excessive back pressure.

Can the Baumalight MS960 run on a standard-flow skid steer?

The MS960 can be paired with a C930 motor starting at 20 GPM, but because it is a heavy-duty 900 Series mulcher with a 7,000 lb minimum carrier requirement, it is best suited for larger skid steers and compact track loaders with strong hydraulic output.

Is the Baumalight MS960 good for high-flow skid steers?

Yes. The MS960 is well suited for high-flow skid steers and compact track loaders. Common pairings include the C930 for 25–30 GPM, C940 for 31–35 GPM, C950 for 36–40 GPM, C970 for 41–50 GPM, and the D97X2 two-speed motor for adjustable high-flow performance.

What is the cutting width of the Baumalight MS960?

The Baumalight MS960 has a 60-inch rotor width and a 75-inch path width.

How many teeth are on the Baumalight MS960?

The MS960 uses 38 R9000 double-tipped cutters.

What is the difference between the Baumalight MS960 and MS972?

The MS960 has a 60-inch rotor width and 75-inch path width. The MS972 is the wider version with a 72-inch rotor width and 84-inch path width. The MS960 requires a 7,000 lb minimum carrier, while the MS972 requires a 7,500 lb minimum carrier.

Can the MS960 fit a Bobcat skid steer or compact track loader?

Yes, the MS960 uses a universal skid steer quick-attach mount and may fit larger Bobcat machines such as the T740, T770, T870, S740, S770, and S850. Always confirm hydraulic flow, pressure, case drain, carrier weight, lift capacity, and coupler compatibility before ordering.

Are hydraulic couplers included with the Baumalight MS960?

No. Hydraulic couplers are not included because coupler requirements vary by skid steer brand and model. Couplers should be matched to your machine before delivery.

Should I choose Ripper teeth or Planer teeth?

Choose Ripper teeth for mixed clearing, ground contact, rocky conditions, fence rows, vines, and rough vegetation management. Choose Planer teeth for cleaner wood and brush when you want more efficient cutting and there are fewer stones or ground-contact hazards.
